Duratron® CU60 PBI

preto

The Duratron® CU60 PBI offers the highest temperature resistance and the best retention of mechanical properties above 200 ° C of all thermoplastics.

The Duratron® CU60 PBI is very "clean" in terms of ionic impurity. These features make this material extremely useful for high-tech industries such as the semiconductor and aerospace industries. It is typically used on critical components to lower maintenance costs and obtain valuable production time.

Set up your product


Format

Chemical

Resistance

Electrical

Insulation

Wear

resistance

sliding

properties

impact

resistance

+310ºC / -50ºC

temperature range

MAIN CHARACTERISTICS

- Extremely high maximum allowable service temperature in air [310 °C continuously, up to 500 °C for short periods of time]

- Excellent retention of mechanical strength, stiffness and creep resistance over a wide temperature range

- Excellent wear and frictional behaviour

- Extremely low coefficient of linear thermal expansion

- Excellent resistance against high energy radiation [gamma- and X-rays]

- Inherent low flammability

- High purity in terms of ionic contamination

- Good electrical insulating and dielectric properties

Aplicações

- Critical components to decrease maintenance costs and to gain valuable production “uptime”

- Replace metals and ceramics in pump components, valve seats [high tech valves], bearings, rollers, high temperature insulators.

Downloads

Duratron® PBI - Technical Datasheet

Duratron® PBI - Delivery Program
